| Chip type | AR0246 |
| Array size | 1920H x 1080V |
| AVDD (Analog Voltage) | (Typ. 2.8V) |
| DVDD (Digital Voltage) | (Typ. 1.0V) |
| DOVDD (IO Voltage) | (Typ. 1.8V) |
| Sensor CRA | 10° |
| Sensor IIC Address | SID = 0 0X06C 0X008 |
| Pixel Size | 2.0um*2.0um |
| EFL (Effective Focal Length) | 2.07mm |
| F/NO (Aperture) | 2.6±5% |
| View angle | D109° H95.6° V63° |
| TV - Distortion | < -8.83% |
| Focusing range | TBD |
| Chief Ray Angle | 19.25° |
| COMPOSITION | 4E + IR |
| FILTER | 650nm |
