Substrate | PCB |
Module size | 52.52725.55mm |
Sensor Type | IMX678 - AAQRI - C |
Array Element | 3840 (H) × 2160 (V) |
Pixel Size | 2.0 μm (H) × 2.0 μm (V) |
Power Supply - AVDD (Analog Voltage) | 3.3V |
Power Supply - DVDD (Digital Voltage) | 1.1V |
Power Supply - I/O (Input/Output) | 1.8V |
Temperature Range - Working temperature | -30℃~85℃ |
Temperature Range - Save temperature | -40℃~80℃ |
Max Frame rate | 12 bit: 60 frame/s, 10 bit: 72 frame/s |
Output Formats | RAW10 / RAW12 |
Encapsulation mode | COB |
Lens size | 1/1.8" |
Lens Construction | 7G |
F/No | 2.2 |
EFL | 3.4mm |
Optical FOV | D:H:V = 160°:136°:72° |
For any other requirements, please email:union@unimage.com.cn
High - quality lmage and Stability
Excellent optical performance: Fixed -focus lenses havea simple structure, with better distortion control andlight -passing capacity than zoom lenses. They canmaintain clear images especiallyin low-lightenvironments(such as backlit conference rooms).
Reliability of fixed viewing angle: No need to frequentlyadjust the focal length, avoiding the noise of zoommotors and the risk of mechanical failures, suitable forlong-term stable operation.
Cost and Deployment Efficiency
High cost-effectiveness: The cost of fixed - focusmodules is significantly lower than that of motorizedzoom solutions, making them suitable for small -andmedium -sized enterprises or standard conferencerooms with limited budgets.
Quick installation: No complex debugging is required.Preset viewing angles (such as 60°-90° horizontally) aresuitable for common conference layouts(round tables.U -shaped tables).
Typical Scenarios
Personal/small -scale meetings: Single - person desks,3-5 -person group discussions (the camera covers theseating area fixedly).
Educational recording and online courses: Fixedposition shooting of lecturersor blackboards,combined with Al tracking for automatic framecropping.
Embedded device integration: Integrated into devicessuch as conference tablets and Soundbars to meetbasic video - calling requirements.
