| hip type | IMX258(COB) |
| EFL (Effective Focal Length) | 6.78mm |
| Array size | 4224*3192 (13M) |
| F/NO (Aperture) | 2.4±6.7% |
| AVDD (Analog Voltage) | (Typ.2.8V) |
| View angle (Field of View) | 46° ±3°(D) |
| DVDD (Digital Voltage) | (Typ.1.2V) |
| TV - Distortion | <1.0% |
| DOVDD (I/O Voltage) | (Typ.1.8V) |
| Focusing range | AT=5m 30cm - INF |
| Sensor CRA | 32°(Img100%) |
| Chief Ray Angle | <25° |
| Sensor IIC Address | SID=1, 0X20(w)/0X21(R) |
| COMPOSITION | 5P |
| Pixel Size | 1.12um×1.12um |
| FILTER | filter:650nm Blue Glass |
