| Lens Construction (CONSTRUCTION) | 6G+IR |
| Pixel Size | 2.9um*2.9um |
| EFL (Effective Focal Length) | 2.2mm |
| Active Pixel Array (Resolution) | 1920x1080 |
| F/NO (Aperture) | 2.5±5% |
| Optical Format | 1/2.8 Inch |
| FOV (Field of View) | D:164° H:142° V:81° |
| Sensor IIC Address (Sensor IIC) | 0x34 (W) |
| Distortion | Op - D < -87.6% |
| PDN Control (High/Low Effective) | / |
| Focusing Range | / |
| RESETB Control (High/Low Effective) | Low effective (Internal Pull - up Control) |
| Image Circle | Φ6.3mm |
| IR Type (IR/BG) | IR |
For any other requirements, please email:union@unimage.com.cn
TI's FPD -Link(Flat Panel Display Link)technology is specifically designed for high -speed, long-distance video transmissionand has the following characteristics inAGVs/robots:
Interference -resistant Transmission :
It transmits uncompressed video data viacoaxial cables or twisted - pair wires, with amaximum transmission distance of up to 15meters(FPD-Linkll),adapting to theelectromagnetic interference environmentin factories.
Multi-camera SynchronizationSupports multi-channel cameras to betransmitted through a single link, reducingwiring complexity(for example, 4 camerassharing 1 cable).
Low Latency and High Bandwidth:
Supports 720p/1080p@60fps video streams,meeting real-time decision -makingrequirements (such as anobstacleavoidance response time< 100ms).
Power over Coax (PoC):
It supplies power through coaxial cables(Power over Coax),reducing the need forindependent power cables and simplifyingsystem integration.
