Global Shutter: Eliminates the jelly effect caused by high - speed movement, suitable for AGV dynamic environments (such as precise image capture when the traveling speed is ≥2m/s).
High Dynamic Range (HDR): Supports a 120dB dynamic range, adapting to extreme lighting changes in warehouses, including strong light (direct sunlight through skylights) and dark areas (shelter shadows).
Industrial - grade Protection: IP67 enclosure, withstanding a temperature range from - 40°C to 105°C, dust - proof and waterproof, suitable for cold chain warehousing or outdoor scenarios.
Long - distance Transmission: Achieves 15 - meter relay - free transmission through a single coaxial cable, reducing the wiring complexity of the AGV body.
Multi - camera Cascade: Supports the cascading of 4 cameras, with a single - link bandwidth of 6Gbps, meeting the synchronous requirements of multiple sensors.
Bidirectional Control: Adjusts camera parameters (such as exposure time, gain) in real - time through I²C/UART, adapting to dynamic environments.
Transmission Delay: End - to - end delay ≤50ms (including encoding, transmission, and decoding), meeting the real - time obstacle avoidance requirements of AGVs.
Power Consumption Optimization: The power consumption of a single - camera module is ≤2.5W, and the standby power consumption of MAX96717F is <100mW, suitable for battery - powered AGVs.
