| Substrate | RFPC |
| Module size | 6.96.95.17mm |
| Sensor Type | IMX681 - AAQH5 - C |
| Stable Image temperature | 0~60℃ |
| Array Element | 4048 (H) × 3104 (V) |
| Pixel Size | 1.0 μm (H) × 1.0 μm (V) |
| Power Supply - AVDD | 3.3V |
| Power Supply - DVDD | 1.05V |
| Power Supply - I/O | 1.8V |
| Temperature Range - Operation temperature | -20~70℃ |
| Temperature Range - Storage temperature | -30~80℃ |
| Max Frame rate | 30fps |
| Output Formats | RAW/10/8 |
| Encapsulation mode | COB |
| Lens size | 1/3.57" |
| Lens Construction | 6P |
| F/No | 2.25±5% |
| EFL (Effective Focal Length) | 1.912mm |
| Optical FOV (Field of View) | D109.6° H93.7° V76.5° |
