| Total Track Length (TTL) | 6.12 |
| Sensor Type | IMX71 |
| MIPI Type | N/A |
| Lens Thread | M6.8*0.25 |
| Sensor Vendor | Sony |
| MIPI Vendor | N/A |
| Lens Construction | 6P |
| Pixel Size | 1.0um*1.0um |
| Driver IC Model | N/A |
| EFL (Effective Focal Length) | 2.26mm |
| Array Element (Resolution) | 3650*2496 |
| Driver IC Address | N/A |
| F/NO (Aperture) | 2.2 |
| Optical Format | 1/3.09 Inch |
| EEPROM Model | CX20564PL - M1R |
| FOV (Field of View) | D118.9° H94.6° V75.3° |
| Sensor IIC Address | 0x20 (W)/0x21 (R) |
| EEPROM Address | 0x30 (W)/0x31 (R) |
| Distortion | <-10.9% |
| PDN Control (High/Low Effective) | / |
| Sensor Type | N/A |
| Focusing Range | AT=1.2M 60CM - INF |
| RESETB Control (High/Low Effective) | Low effective |
| Base | N/A |
| Image Circle | Φ6.06mm |
| IR Type (IR/BG) | BG |
| Lens CRA (Chief Ray Angle) | 34.95° |
| Sensor CRA (Chief Ray Angle) | 36° |
