| Module size | 6814.54.885mm |
| Sensor Type | OV07251 - A35A - IJ |
| Stable Image Temperature | 0~50°C |
| Array Element | 640H x 480V |
| Pixel Size | 3um*3um |
| Power Supply | |
| - Analog Power (AVDD) | 2.8V |
| - Digital Power (DVDD) | 1.5V |
| - I/O | 1.8V |
| Lighting Temperature Range | |
| - Operating Temperature Range | -30°C~70°C |
| - Storage Temperature | -40~+85°C |
| Max Frame Rate | 640*480:100fps |
| Output Formats | 10 - bit RGB RAW or BW |
| Encapsulation Mode | CSP |
| Lens Size | 1/7.5” |
| Lens Construction | 3P+IR |
| F/No | 3.6±5% |
| EFL (Effective Focal Length) | 2.45mm |
| Optical FOV (Field of View) | D45.7° H37° V28.1° |
Premium Services We offer customized services and support for relevant development driver packages.
For any other requirements, please email:union@unimage.com.cn
For any other requirements, please email:union@unimage.com.cn
Consumer - grade Aerial Photography
Technical Features: 4K/8K video + 3 - axis gimbal anti - shake
Application Scenarios: Travel photography, event recording, film and television production
Agricultural Monitoring
Technical Features: Multispectral/hyperspectral imaging + NDVI (Normalized Difference Vegetation Index) analysis
Application Scenarios: Crop health assessment, pest and disease early warning, precision fertilization
Surveying and Mapping & Modeling
Technical Features: RTK (Real - Time Kinematic) positioning + oblique photography (five lenses)
Application Scenarios: Terrain surveying and mapping, building 3D modeling, earthwork calculation
Emergency Rescue
Technical Features: Thermal imaging + zoom lens (30x optical)
Application Scenarios: Forest fire monitoring, night search and rescue, disaster area assessment
Industrial Inspection
Technical Features: LiDAR (Light Detection and Ranging) + obstacle avoidance system
Application Scenarios: Power line inspection, wind turbine blade detection, pipeline leakage positioning
Environmental Monitoring
Technical Features: Gas sensor + wide - angle lens
Application Scenarios: Air quality detection, pollution source tracking, wildlife observation
