Camera Specification:
Streaming Media Camera Module Camera Datasheet
UIV-SC035HGS-One-line laser-MIPI-CZMVF3092
Application Field
Sweeping robot
Sensor
DVS
Package Type
CSP
Chip Target Surface
1/6.0
Resolution
-
Frame Rate
-
Interface
MIPI
ChromaType
Mono
Shutter Type
GS
$38.00
$38.00
Inventory:995
Want to know more about it, please email union@unimage.com.cn
  • FEATURES
  • APPLICATION
Module No. CZMVF3092 - V1
Substrate FPC
Module size 6.56.55.17mm
Sensor Type SC035HGS - CSMNN00
Array Element 640H×480V
Pixel Size 3.744μm×3.744μm
Power Supply - AVDD 2.8V
Power Supply - DVDD 1.5V
Power Supply - I/O 1.8V
Temperature Range - Operating Temperature Range -30℃ - 85℃
Temperature Range - Optimal Operating Temperature Range -20℃ - 60℃
Max Frame rate 640H×480V @180fps (KPC eff)
Output Formats RAW RGB
Encapsulation mode CSP
Lens size 1/6”
Lens Construction 3P+650IR
F/No 2.4±5%
EFL (Effective Focal Length) 1.323mm
Optical FOV (Field of View) D141.8° H106.1° V78°

The single-line laser module represents a crucial leap for robot vacuums, evolving from “blindly bumping” to “smart path - planning”.
Though not all - powerful, it remains a dominant sensor in mid - to - high - end robot vacuums, thanks to its high cost - effectiveness and mature navigation and mapping capabilities. In the future, by fusing with vision, inertia, and other sensors, it will bring more 智能化 (intelligent possibilities) to home cleaning robots.
Multi - modal Fusion Navigation
Laser + Visual (VSLAM) + IMU enables smarter obstacle avoidance and recognition.
Laser - AI Integration
AI automatically identifies scene types (carpet, floor, obstacle type).
Structural Simplification + Cost Optimization
More compact module design, suitable for slim robot vacuums.
Cloud Intelligence and OTA Upgrades
Laser module data is uploaded to the cloud for training, enabling smarter map - building capabilities.
